XM-E272-0409D
XR-E272-0409D ROHS

Switch, PE42528A [PCB: 3231]
Recommended Bias Controller: XM-A6K1-0409D-SP

Product Page

 N/A pSemi

Spec Sheet

 N/A PE42528A

Low Freq

 N/A 0.01 MHz

High Freq

 N/A 32000 MHz

IL

 N/A 1.3 dB

P1dB

 N/A 29 dBm

IP3

 N/A 48 dBm

Bias Instruction

 N/A

Notes: V1,2 LOW = -3V @390nA typ
V1,2 HIGH = +3V @390nA typ

State 1: [V1 = LOW] [V2 = LOW] [RF1 = OFF] [RF2 = OFF]
State 2: [V1 = LOW] [V2 = HIGH] [RF1 = OFF] [RF2 = ON]
State 3: [V1 = HIGH] [V2 = LOW] [RF1 = ON] [RF2 = OFF]

Part Number

 N/A XR-E272-0409D
