XM-E234-0409D
XR-E234-0409D ROHS

Switch, FW2001 [PCB: 3338]
Recommended Bias Controller: XM-E2N4-0409D-SP

Product Page

 N/A Finwave

Spec Sheet

 N/A FW2001

Low Freq

 N/A 30 MHz

High Freq

 N/A 12000 MHz

IL

 N/A 0.95 dB

P1dB

 N/A 41 dBm

IP3

 N/A 66 dBm

N/A

Bias Instruction

 N/A

Notes: VCTRL1,2 = -5V @-60nA(LOW) or +5V @120uA(HIGH)

State 1: [CTRL1 = HIGH] [CTRL2 = LOW] [RF1 = ON] [RF2 = OFF]
State 2: [CTRL1 = LOW] [CTRL2 = HIGH] [RF1 = OFF] [RF2 = ON]

Part Number

 N/A XR-E234-0409D
