XM-E1J4-0404D
XR-E1J4-0404D ROHS

Amplifier, CMX90B702QF [PCB: 3439]

Product Page

 N/A CML Micro

Spec Sheet

 N/A CMX90B702QF

Low Freq

 N/A 23000 MHz

High Freq

 N/A 29500 MHz

Gain

 N/A 17.5 dB

NF

 N/A 4 dB

P1dB

 N/A 5 dBm

IP3

 N/A 15 dBm

Voltage

 N/A 3 V

Current

 N/A 10 mA

Bias Instruction

 N/A

Power-up Sequence
1. Apply VD = +4V
2. Apply EN = +4V @0.37mA (ON)
Verify ID ~10mA (low current mode)
3. Apply RF Input

Power-down Sequence
1. Remove RF Input
2. Adjust EN to 0V (OFF)
2. Adjust VD to 0V

Part Number

 N/A XR-E1J4-0404D
