XM-D284-0404D
XR-D284-0404D ROHS

Amplifier, ADPA7008CHIP [PCB: 1724]
Recommended Bias Controller: XM-D285-0404D-SP

Product Page

 N/A ADI

Spec Sheet

 N/A ADPA7008CHIP

Low Freq

 N/A 20000 MHz

High Freq

 N/A 54000 MHz

Gain

 N/A 18 dB

NF

 N/A 7.5 dB

P1dB

 N/A 30.5 dBm

IP3

 N/A 38 dBm

Voltage

 N/A 4 V

Current

 N/A 1500 mA

N/A

Bias Instruction

 N/A

Power-up Sequence
1. Apply VGG = -1.5V
2. Apply VDD = +5V
3. Adjust VGG more positive until IDQ reaches 1500mA
Note: Do not exceed 0V.
4. Apply the RF input signal



Power-down Sequence
1. Turn off the RF input signal
2. Adjust VGG to -1.5V
3. Adjust VDD to 0V
4. Adjust VGG to 0V

Note: Very Hot, use cooling fan

Part Number

 N/A XR-D284-0404D
