XM-C458-0404C-01
XR-C458-0404C-01 ROHS

Amplifier, HMMC-5628-BLK [PCB: 1459]
Included Bias Controller: XM-A2J9-0404D

Configurations

Product Page

 N/A Keysight

Spec Sheet

 N/A HMMC-5628-BLK

Low Freq

 N/A 0 MHz

High Freq

 N/A 26500 MHz

Gain

 N/A 17 dB

Voltage

 N/A 3.3 V

Current

 N/A 30 mA

Connector Series

 N/A SuperSMA

Bias Instruction

 N/A

Power-up Sequence
1. Set +VIN to +5.5V min. [+15V max]
2. Apply the RF input signal



Power-down Sequence
1. Remove the RF input signal
2. Set +VIN to 0V

Part Number

 N/A XR-C458-0404C-01
