XM-A7U7-0404D
XR-A7U7-0404D ROHS

Amplifier, CHA4220-QGG [PCB: 3047]
Recommended Bias Controller: XM-A7U8-0404D

Product Page

 N/A UMS

Spec Sheet

 N/A CHA4220-QGG

Low Freq

 N/A 500 MHz

High Freq

 N/A 20000 MHz

Gain

 N/A 17 dB

NF

 N/A 3 dB

P1dB

 N/A 20 dBm

IP3

 N/A 28 dBm

Voltage

 N/A 6.5 V

Current

 N/A 120 mA

N/A

Bias Instruction

 N/A

Power-up Sequence:
1) Ground the device.
2) Set Vg1 to -1.5V.
3) Set Vd to 6.5V (nominal value for Vd).
4) Set Vg2 to 1.5V (nominal value for Vg2).
5) Set Vg1 in the range of -0.3V for having Idq=120mA.
6) Apply RF input power and adjust Vg2 to obtain desired gain.

Power-down Sequence:
1) Turn RF power supply off.
2) Set Vg1 to -1.5V in order to get Idq=0mA.
3) Set Vg2 to 0V.
4) Set Vd to 0V.
5) Set Vg1 to 0V.

Part Number

 N/A XR-A7U7-0404D
