XM-A667-0404D
XR-A667-0404D ROHS

Amplifier, HMC341LC3B [PCB: 0560]
Recommended Bias Controller: XM-A2R9-0404D-SP

Configurations

Product Page

 N/A ADI

Spec Sheet

 N/A HMC341LC3B

Low Freq

 N/A 21000 MHz

High Freq

 N/A 29000 MHz

Gain

 N/A 13 dB

NF

 N/A 2.5 dB

P1dB

 N/A 8.5 dBm

IP3

 N/A 19 dBm

Voltage

 N/A 3 V

Current

 N/A 35 mA

ALL_ASSET

 N/A 1233P 1234M 1235M

Bias Instruction

 N/A

Power-up Sequence
1. Apply VDD = 3.0V
Verify IDD ~35mA
2. Apply RF Input

Power-down Sequence
1. Remove RF Input
2. Turn off VDD

Part Number

 N/A XR-A667-0404D
