XM-A3Y1-0404C-01
XR-A3Y1-0404C-01 ROHS

Amplifier, MAAL-011129 [PCB: 0404]
Included Bias Controller: XM-A2J9-0404D

Configurations

Product Page

 N/A Macom

Spec Sheet

 N/A MAAL-011129

Low Freq

 N/A 18000 MHz

High Freq

 N/A 31500 MHz

Gain

 N/A 23 dB

NF

 N/A 2.5 dB

P1dB

 N/A 16 dBm

IP3

 N/A 25 dBm

Voltage

 N/A 3 V

Current

 N/A 50 mA

ALL_ASSET

 N/A 1007P 5053M

Connector Series

 N/A 2.92mm

N/A

Bias Instruction

 N/A

Power-up Sequence
1. Set +VIN to 5.5V
2. Apply the RF input signal



Power-down Sequence
1. Remove the RF input signal
2. Set +VIN to 0V

Part Number

 N/A XR-A3Y1-0404C-01
