XM-A152-0404C
XR-A152-0404C ROHS

Amplifier, GALI-74+ [PCB: 0530]

Configurations

Configurations

Product Page

 N/A Mini-Circuits

Spec Sheet

 N/A GALI-74+

Low Freq

 N/A 50 MHz

High Freq

 N/A 1000 MHz

Gain

 N/A 21.8 dB

NF

 N/A 2.7 dB

P1dB

 N/A 19.2 dBm

IP3

 N/A 33 dBm

Voltage

 N/A 5 V

Current

 N/A 80 mA

ALL_ASSET

 N/A 1007P 1124M

Connector Series

 N/A SuperSMA

N/A

Bias Instruction

 N/A

Power-up Sequence
1. Apply VDD = 7.0V
Verify IDD ~80mA
2. Apply RF Input

Power-down Sequence
1. Remove RF Input
2. Turn off VDD

Part Number

 N/A XR-A152-0404C
